- Product Model 74HC02D
- Brand Toshiba Electronic Devices and Storage Corporation
- RoHS 1
- Description IC GATE NOR 4CH 2-INP 14SOIC
- Classification Integrated Circuits - ICs
-
PDF
- 2500 0.2
- 5000 0.19
- 12500 0.17
- 25000 0.16
Technical Details
- Package / Case 14-SOIC (0.154", 3.90mm Width)
- Mounting Type Surface Mount
- Logic Type NOR Gate
- Operating Temperature -40°C ~ 85°C
- Voltage - Supply 2V ~ 6V
- Current - Output High, Low 5.2mA, 5.2mA
- Number of Inputs 2
- Supplier Device Package 14-SOIC
- Input Logic Level - High 1.5V ~ 4.2V
- Input Logic Level - Low 0.5V ~ 1.8V
- Max Propagation Delay @ V, Max CL 16ns @ 6V, 50pF
- Number of Circuits 4
- Current - Quiescent (Max) 1 µA
