Technical Details

• Package / Case TO-236-3, SC-59, SOT-23-3
• Mounting Type Surface Mount
• Transistor Type NPN
• Operating Temperature -55°C ~ 150°C (TJ)
• Vce Saturation (Max) @ Ib, Ic 500mV @ 100mA, 1A
• Current - Collector Cutoff (Max) 100nA
• DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 500mA, 5V
• Frequency - Transition 150MHz
• Supplier Device Package SOT-23-3
• Current - Collector (Ic) (Max) 1 A
• Voltage - Collector Emitter Breakdown (Max) 60 V
• Power - Max 600 mW
