Technical Details

• Package / Case SC-74A, SOT-753
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 300mA
• Operating Temperature -40°C ~ 125°C (TA)
• Output Configuration Positive
• Current - Quiescent (Iq) 55 µA
• Voltage - Input (Max) 5.5V
• Number of Regulators 1
• Supplier Device Package SOT-23-5
• Voltage - Output (Min/Fixed) 3.3V
• Control Features Enable
• Grade Automotive
• PSRR 68dB (1kHz)
• Voltage Dropout (Max) 0.375V @ 300mA
• Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
• Current - Supply (Max) 370 µA
• Qualification AEC-Q100
