Technical Details

• Package / Case TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
• Mounting Type Surface Mount
• Operating Temperature -55°C ~ 150°C (TJ)
• Technology MOSFET (Metal Oxide)
• FET Type N-Channel
• Current - Continuous Drain (Id) @ 25°C 10.5A (Tc)
• Rds On (Max) @ Id, Vgs 750mOhm @ 5.25A, 10V
• Power Dissipation (Max) 190W (Tc)
• Vgs(th) (Max) @ Id 4.5V @ 100µA
• Supplier Device Package D2PAK
• Drive Voltage (Max Rds On, Min Rds On) 10V
• Vgs (Max) ±30V
• Drain to Source Voltage (Vdss) 800 V
• Gate Charge (Qg) (Max) @ Vgs 87 nC @ 10 V
• Input Capacitance (Ciss) (Max) @ Vds 2620 pF @ 25 V
