- Product Model CDSOT23-SM712
- Brand J.W. Miller / Bourns
- RoHS 1
- Description TVS DIODE 7V/12V 14V/26V SOT23-3
- Classification Integrated Circuits - ICs
-
PDF
- 3000 0.62
- 6000 0.59
- 9000 0.56
Technical Details
- Package / Case TO-236-3, SC-59, SOT-23-3
- Mounting Type Surface Mount
- Type Zener
- Operating Temperature -55°C ~ 150°C (TJ)
- Applications RS-485
- Capacitance @ Frequency 75pF @ 1MHz
- Current - Peak Pulse (10/1000µs) 17A (8/20µs)
- Voltage - Reverse Standoff (Typ) 12V (Max), 7V (Max)
- Supplier Device Package SOT-23-3
- Bidirectional Channels 2
- Voltage - Breakdown (Min) 13.3V, 7.5V
- Voltage - Clamping (Max) @ Ipp 26V, 14V
- Power - Peak Pulse 400W
- Power Line Protection No
