Technical Details

• Package / Case 8-SOIC (0.154", 3.90mm Width)
• Output Type Open Collector, Schottky Clamped
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C
• Voltage - Supply 4.5V ~ 5.5V
• Voltage - Forward (Vf) (Typ) 1.3V
• Data Rate 10MBd
• Input Type DC
• Voltage - Isolation 3750Vrms
• Current - DC Forward (If) (Max) 10mA
• Inputs - Side 1/Side 2 2/0
• Supplier Device Package 8-SO Tall
• Rise / Fall Time (Typ) 42ns, 12ns
• Common Mode Transient Immunity (Min) 15kV/µs
• Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
• Number of Channels 2
• Current - Output / Channel 50 mA
