技术参数

• Features Keying Slot
• Connector Type Header
• Voltage Rating 250V
• Current Rating (Amps) 3A
• Mounting Type Through Hole, Right Angle
• Number of Positions 10
• Number of Rows 2
• Style Board to Cable/Wire
• Operating Temperature -40°C ~ 125°C
• Contact Type Male Pin
• Fastening Type Push-Pull
• Number of Positions Loaded All
• Termination Solder
• Material Flammability Rating UL94 V-0
• Contact Material Copper Alloy
• Insulation Color Black
• Pitch - Mating 0.100" (2.54mm)
• Contact Finish - Mating Gold
• Contact Shape Square
• Contact Length - Post 0.118" (3.00mm)
• Insulation Height 0.358" (9.10mm)
• Shrouding Shrouded - 4 Wall
• Insulation Material Polybutylene Terephthalate (PBT)
• Row Spacing - Mating 0.100" (2.54mm)
• ECCN EAR99
• HTSUS 8536.69.4040
• Moisture Sensitivity Level (MSL) 1 (Unlimited)
• REACH Status REACH Unaffected
• RoHS Status ROHS3 Compliant
