Technical Details

• Tolerance ±20%
• Package / Case 2-SMD
• Size / Dimension 0.287" L x 0.260" W (7.30mm x 6.60mm)
• Mounting Type Surface Mount
• Shielding Shielded
• Type Molded
• Operating Temperature -40°C ~ 125°C
• DC Resistance (DCR) 40mOhm Max
• Frequency - Self Resonant 22MHz
• Current - Saturation (Isat) 15.5A
• Material - Core Iron Powder
• Inductance Frequency - Test 100 kHz
• Height - Seated (Max) 0.122" (3.10mm)
• Inductance 4.7 µH
• Current Rating (Amps) 3.8 A
• ECCN EAR99
• HTSUS 8504.50.4000
• Moisture Sensitivity Level (MSL) 1 (Unlimited)
• REACH Status REACH Unaffected
• RoHS Status ROHS3 Compliant
